Using Sitemesh and Got Error 330 (net::ERR_CONTENT_DECODING_FAILED) on Google Chrome

Basically i never had this error before, it become so challenging because it happen after i adding sitemesh library on my maven project. My first guess is, somehow Sitemesh have a conflicting configuration with other libraries. But i never found any reference nor article to support my theory. Even after i heavily removed several library, the error still happens.

Suddenly i have an enlightenment, after i remove my ehcache gzip compression filter. It turns out that in order to work i need to put sitemesh filter location after ehcache gzip filter.

Here is my final web.xml looks like,

<?xml version="1.0" encoding="UTF-8"?>
<web-app version="3.0" xmlns="http://java.sun.com/xml/ns/javaee" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd">

    <!-- gzip -->
    <filter>
        <filter-name>CompressionFilter</filter-name>
        <filter-class>net.sf.ehcache.constructs.web.filter.GzipFilter</filter-class>
    </filter>
    <filter-mapping>
        <filter-name>CompressionFilter</filter-name>
        <url-pattern>/*</url-pattern>
    </filter-mapping>

    <!-- sitemesh -->
    <filter>
        <filter-name>sitemesh</filter-name>
        <filter-class>com.opensymphony.sitemesh.webapp.SiteMeshFilter</filter-class>
    </filter>
    <filter-mapping>
        <filter-name>sitemesh</filter-name>
        <url-pattern>/*</url-pattern>
    </filter-mapping>

</web-app>
Google+

[Java] Creating a Microsoft Word Report Easily using Servlet and A Plain HTML Template

Yesterday one of my friend, Edward Barchia, asked me a very simple question, “how can i creating an MSWord Report without using Jasper Report”. Because somehow, jasper report creates a very weird output when exported into Word file (.doc).

One fastest solution is using a html file, and renamed into .doc. Not an elegant solution, but perhaps (at that moment) is the best solution we had.

Okay, so basically what i need is only 2 files, 1 html template and a java servlet files. This is my HTML template, i put it on drie E and name it hello.html

<html>
	<head></head>
	<body>
		Test, hello ${name}
	</body>
</html>

And this is my servlet file,

package com.edw.testdownloaddoc.servlet;

import java.io.BufferedReader;
import java.io.FileInputStream;
import java.io.FileReader;
import java.io.IOException;
import java.io.OutputStream;
import javax.servlet.ServletException;
import javax.servlet.annotation.WebServlet;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import org.apache.commons.io.IOUtils;

@WebServlet(name = "downloadServlet", urlPatterns = {"/downloadServlet"})
public class DownloadServlet extends HttpServlet {

    protected void processRequest(HttpServletRequest request, HttpServletResponse response)
            throws ServletException, IOException {
        BufferedReader downloadFile = new BufferedReader(new FileReader("e:\\hello.html"));
        FileInputStream inputStream = null;
        OutputStream outStream = null;
        try {
            String s;
            StringBuilder sb = new StringBuilder();
            while ((s=downloadFile.readLine()) != null) {
                if(s.contains("${name}"))
                    s = s.replace("${name}", "Edwin");
                sb.append(s);
            }

            response.setContentLength((int) sb.toString().length());
            response.setContentType("application/msword");

            // response header
            String nameFile = "hello.doc";
            String headerKey = "Content-Disposition";
            String headerValue = String.format("attachment; filename=\"%s\"",nameFile);
            response.setHeader(headerKey, headerValue);

            // Write response
            outStream = response.getOutputStream();
            IOUtils.write(sb.toString(), outStream);
        } catch (Exception e) {
            e.printStackTrace();
        } finally{
            IOUtils.closeQuietly(downloadFile);
            IOUtils.closeQuietly(inputStream);
            IOUtils.closeQuietly(outStream);
        }
    }

    @Override
    protected void doGet(HttpServletRequest request, HttpServletResponse response)
            throws ServletException, IOException {
        processRequest(request, response);
    }
}

Oh, and before i forgot, this is my pom.xml dependencies

<dependencies>
	<dependency>
		<groupId>commons-io</groupId>
		<artifactId>commons-io</artifactId>
		<version>2.2</version>
	</dependency>
	<dependency>
		<groupId>javax</groupId>
		<artifactId>javaee-web-api</artifactId>
		<version>7.0</version>
		<scope>provided</scope>
	</dependency>
</dependencies>

This is the final output looks like,
helloworld

Google+

Logging HTTP Request Parameters using HTTP Servlet

This is a servlet filter that i use if i want to log what parameters fired by my REST client, basically it’s just a simple http servlet filter.

package com.edw;

import java.io.IOException;
import java.util.Enumeration;
import javax.servlet.Filter;
import javax.servlet.FilterChain;
import javax.servlet.FilterConfig;
import javax.servlet.ServletException;
import javax.servlet.ServletRequest;
import javax.servlet.ServletResponse;
import javax.servlet.http.HttpServletRequest;
import org.apache.log4j.Logger;

public class LoggingFilter implements Filter {

    private Logger logger = Logger.getLogger(this.getClass());

    @Override
    public void init(FilterConfig filterConfig) throws ServletException {
    }

    @Override
    public void doFilter(ServletRequest request, ServletResponse response, FilterChain chain) throws IOException, ServletException {

        try {
            HttpServletRequest req = (HttpServletRequest) request;

            String uri = req.getRequestURI();
            logger.debug("Requested Resource::"+uri);

            Enumeration<String> enumeration = req.getParameterNames();

            while(enumeration.hasMoreElements()) {
                String parametername = enumeration.nextElement();
                logger.debug(parametername + " : " +req.getParameter(parametername));
            }
        } catch (Exception e) {
            logger.error(e,e);
        }

        chain.doFilter(request, response);
    }

    @Override
    public void destroy() {
    }
}

Add your servlet filer to your web.xml and listen for a specific url request, on this example i listen for requests to /services/ url.

<?xml version="1.0" encoding="UTF-8"?>
<web-app version="3.0" xmlns="http://java.sun.com/xml/ns/javaee" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd">
    <session-config>
        <session-timeout>
            30
        </session-timeout>
    </session-config>

    <filter>
	<filter-name>LogFilter</filter-name>
	<filter-class>
		com.edw.LoggingFilter
	</filter-class>
    </filter>
    <filter-mapping>
            <filter-name>LogFilter</filter-name>
            <url-pattern>/services/*</url-pattern>
    </filter-mapping>
</web-app>
Google+

How to Create A Simple Captcha Using Java Servlet

On this article im going to create a simple image captcha that will show a 5-random alphanumeric letters, im using SimpleCaptha library to help me creating images and validating user’s input.

First is a simple java servlet, it will build random images and store its value on httpsession.

package com.edw.captcha;

import java.awt.Color;
import java.awt.Font;
import java.io.IOException;
import java.util.ArrayList;
import java.util.List;
import javax.servlet.ServletException;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import nl.captcha.Captcha;
import nl.captcha.backgrounds.GradiatedBackgroundProducer;
import nl.captcha.servlet.CaptchaServletUtil;
import nl.captcha.text.renderer.DefaultWordRenderer;

public class EdwCaptcha extends HttpServlet {

    @Override
    protected void doGet(HttpServletRequest request, HttpServletResponse response)
            throws ServletException, IOException {
        List<Color> colors = new ArrayList<Color> ();
        colors.add(Color.black);
        colors.add(Color.red);

        List<Font> fonts = new ArrayList<Font>();
        fonts.add(new Font("Arial", Font.ITALIC, 40));

        Captcha captcha = new Captcha.Builder(120, 50)
                .addText(new DefaultWordRenderer(colors, fonts))
                .addBackground(new GradiatedBackgroundProducer(Color.white, Color.white))
                .gimp()
                .addBorder()
                .build();

        // display the image produced
        CaptchaServletUtil.writeImage(response, captcha.getImage());

        // save the captcha value on session
        request.getSession().setAttribute("simpleCaptcha", captcha);
    }
}

And now im registering my servlet on my web.xml,

<?xml version="1.0" encoding="UTF-8"?>
<web-app version="3.0" xmlns="http://java.sun.com/xml/ns/javaee" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd">
    <session-config>
        <session-timeout>
            30
        </session-timeout>
    </session-config>

    <servlet>
        <servlet-name>Captcha</servlet-name>
        <servlet-class>com.edw.captcha.EdwCaptcha</servlet-class>
    </servlet>
    <servlet-mapping>
        <servlet-name>Captcha</servlet-name>
        <url-pattern>/Captcha.jpg</url-pattern>
    </servlet-mapping>
</web-app>

Here is the result image generated from my servlet,

You can validate the submitted captcha values by comparing it with the values that you store in httpsession.

Google+

Connecting MyBatis ORM to C3P0 Connection Pooling

In this example, im trying to connecting my MyBatis application to my database through C3P0 connection pooling. According to its website, C3P0 is an easy-to-use library for making traditional JDBC drivers “enterprise-ready” by augmenting them with functionality defined by the jdbc3 spec and the optional extensions to jdbc2.

Okay, so the first thing i do is, creating a database named “Test” and table “Testing”

CREATE DATABASE `Test`;
USE `Test`;
CREATE TABLE `testing` (
  `Id` int(11) NOT NULL AUTO_INCREMENT,
  `name` varchar(30) NOT NULL DEFAULT '',
  `address` varchar(255) NOT NULL DEFAULT '',
  PRIMARY KEY (`Id`),
  UNIQUE KEY `ix` (`name`)
) ENGINE=InnoDB AUTO_INCREMENT=5 DEFAULT CHARSET=latin1;

insert into `table`(`Id`,`name`,`address`) values (1,'edw','Ciledug');
insert into `table`(`Id`,`name`,`address`) values (2,'kamplenk','Cikokol');
insert into `table`(`Id`,`name`,`address`) values (3,'nugie','Pamulang');
insert into `table`(`Id`,`name`,`address`) values (4,'tebek','Karawaci');

And a java bean class to represent my sql table,

package com.edw.bean;

public class Testing {

    private int id;
    private String name;
    private String address;

    public Testing() {
    }

    // setter and getter method

    @Override
    public String toString() {
        return "Testing{" + "id=" + id + ", name=" + name + ", address=" + address + '}';
    }
}

and dont forget, a java interface class to handle my query

package com.edw.mapper;

import com.edw.bean.Testing;
import java.util.List;
import org.apache.ibatis.annotations.Select;

public interface TestingMapper {
    @Select("SELECT * FROM testing")
    List<Testing> selectAll();
}

Next is creating c3p0 connection configuration on context.xml file under META-INF folder

<?xml version="1.0" encoding="UTF-8"?>
<Context antiJARLocking="true" path="/MyBatisC3P0">

    <Resource name="testjndi"
		 auth="Container"
		 driverClass="com.mysql.jdbc.Driver"
         jdbcUrl="jdbc:mysql://localhost:3306/test"
         user="root"
         password="xxxx"
         factory="org.apache.naming.factory.BeanFactory"
         type="com.mchange.v2.c3p0.ComboPooledDataSource"
         maxPoolSize="30"
         minPoolSize="10"
         acquireIncrement="3"
         acquireRetryAttempts = "0"
         acquireRetryDelay = "3000"
         breakAfterAcquireFailure = "false"
         maxConnectionAge = "20"
         maxIdleTime = "15"
         maxIdleTimeExcessConnections = "15"
         idleConnectionTestPeriod = "10"
         testConnectionOnCheckout = "true"
         preferredTestQuery = "SELECT 1"
         debugUnreturnedConnectionStackTraces = "true"
         autoCommitOnClose="true"
        />
</Context>

next is registering your JNDI on web.xml

<?xml version="1.0" encoding="UTF-8"?>
<web-app version="3.0" xmlns="http://java.sun.com/xml/ns/javaee" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd">
    <servlet>
        <servlet-name>myBatisServlet</servlet-name>
        <servlet-class>com.edw.servlet.MyBatisServlet</servlet-class>
    </servlet>
    <servlet-mapping>
        <servlet-name>myBatisServlet</servlet-name>
        <url-pattern>/myBatisServlet</url-pattern>
    </servlet-mapping>
    <welcome-file-list>
        <welcome-file>myBatisServlet</welcome-file>
    </welcome-file-list>
    <resource-ref>
        <description>My Connection Pool</description>
        <res-ref-name>testjndi</res-ref-name>
        <res-type>javax.sql.DataSource</res-type>
        <res-auth>Container</res-auth>
    </resource-ref>
</web-app>

and calling your connection pooling jndi from MyBatis’ xml code

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
"http://mybatis.org/dtd/mybatis-3-config.dtd">
<configuration>
    <environments default="development">
       <environment id="development">
            <transactionManager type="JDBC"/>
            <dataSource type="JNDI">
                <property name="data_source" value="java:/comp/env/testjndi"/>
            </dataSource>
        </environment>
    </environments>
    <mappers />
</configuration>

next is creating a java class to load my MyBatis’ xml configuration

package com.edw.config;

import com.edw.mapper.TestingMapper;
import java.io.Reader;
import org.apache.ibatis.io.Resources;
import org.apache.ibatis.session.SqlSessionFactory;
import org.apache.ibatis.session.SqlSessionFactoryBuilder;

public class MyBatisSqlSessionFactory {

    private static final SqlSessionFactory FACTORY;

    static {
        try {
            Reader reader = Resources.getResourceAsReader("com/edw/sqlmap/Configuration.xml");
            FACTORY = new SqlSessionFactoryBuilder().build(reader);
            FACTORY.getConfiguration().addMapper(TestingMapper.class);
        } catch (Exception e){
            throw new RuntimeException("Fatal Error.  Cause: " + e, e);
        }
    }

    public static SqlSessionFactory getSqlSessionFactory() {
        return FACTORY;
    }
}

and finally, i create a servlet as my presentation layer

package com.edw.servlet;

import com.edw.bean.Testing;
import com.edw.config.MyBatisSqlSessionFactory;
import com.edw.mapper.TestingMapper;
import java.io.IOException;
import java.io.PrintWriter;
import java.util.List;
import javax.servlet.ServletException;
import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import org.apache.ibatis.session.SqlSession;

public class MyBatisServlet extends HttpServlet {

    protected void processRequest(HttpServletRequest request, HttpServletResponse response)
            throws ServletException, IOException {
        response.setContentType("text/html;charset=UTF-8");
        PrintWriter out = response.getWriter();
        SqlSession sqlSession = MyBatisSqlSessionFactory.getSqlSessionFactory().openSession(true);
        try {
            out.println("<html>");
            out.println("<head>");
            out.println("<title>Servlet MyBatisServlet</title>");
            out.println("</head>");
            out.println("<body>");

            TestingMapper testingMapper = sqlSession.getMapper(TestingMapper.class);
            List<Testing> testings = testingMapper.selectAll();
            for (Testing testing : testings) {
                out.println(testing.getName()+" - "+testing.getAddress()+"<br />");
            }

            out.println("</body>");
            out.println("</html>");
        } finally {
            sqlSession.close();
            out.flush();
            out.close();
        }
    }

    @Override
    protected void doGet(HttpServletRequest request, HttpServletResponse response)
            throws ServletException, IOException {
        processRequest(request, response);
    }
}

This is what the result of my servlet when im running it on my browser

This is the screenshot of my database connection, you can see that c3p0 automatically create 10 free connections.

And this is the screenshot of my netbeans project

Have fun with C3P0 and MyBatis (H)

Google+
